Jet Knife Forming System

Our Jet Knife is an attachment designed for use in conjunction with ourVari-Kut In-Line Grinderparticle reduction system. Ideal for forming individual particulates such as pizza toppings, meatballs, or particulates used in soups and pet food, our Jet Knife can produce product in excess of 10,000 pounds per hour. The Jeft Knife blades are designed to deliver a precise, clean cut that produces consistent particle definition, without smear. The single-cut design results in decreased drying times and increased shelf life. The Jet Knife features a variable-speed hydraulic knife motor that permits control of particle cut length which helps maintain control of the particle length even when feeding multiple downstream machines.

Add to quote

Featured Video

CircFood Jet Knife – Meatballs

Features

  • The Jet Knife blades are designed to deliver a precise, clean cut that produces consistent particle definition, without smear. The single-cut design results in decreased drying times and increased shelf life
  • The variable speed hydraulic knife motor permits control of particle cut length which helps maintain control of particle length even when feeding multiple downstream machines
  • The Jet Knife forming system is designed to give a cleaner particle release
  • Designed to be configured with one uniform size and shape, or each individual hole can be different. This allows the machine to be tailored to fit your needs.
  • Designed specifically for forming individual particulates such as Pizza Toppings, Meatballs, Chili, and Pet Food
  • Made in the USA

Depending on the size of the hole in the forming plate, capacities through the Jet Knife can produce over 10,000 pounds of product
For increased production one CircFood pump can feed two Jet-Knife assemblies
The Jet Knife assembly includes pressure regulator, shaft, gauge, hoses and fittings, one plate (1/4″, 3/8″, 1/2″, 5/8″. or 3/4″), and one knife (even or uneven leg)

Steam Requirements: 80-100 lbs @ 20 PSI

Electrical: 230/460V, 3-Ph/60HZ, 68/34 AMP

Cooling Water: Up to 8 GPM

CircFood Jet Knife Tear Down
